Sangamo Choice 1 Channel Programmer PR1N
Sangamo Choice 1 Channel Programmer PR1N
The Sangamo Choice PR1n is a 1 channel programmer has been designed primarily for timed control of your heating and hot water systems. Sangamo Choice is Ideal for use with a combination (combi) boiler. The PR1n programmer can be configured for 24 hour, 5/2 day or 7 day operation with the flexibility of up to three on/off timings per day.
The Sangamo Choice PR1n is Pre-programmed but can easily be changed to suit your particular lifestyle. Large and clear to read illuminated display. Attractive modern design that will suit all contemporary homes. The Choice PR1n programmer can also be used in conjunction with an existing programmer to control additional heating zones or for when additional hot water cylinder control is required.
Features
- 24 hour, 5/2 day and 7 day selectable
- 2 or 3 ON/OFF periods selectable
- 1, 2 or 3 hour boost
- Advance to next programmed event
- Automatic Summer/Winter time change
- Standard wall plate - simple plug in and replace
Technical Specification
| Power Supply: | 230V AC, 50Hz |
| Operating Temperature: | 0°C to 40°C |
| Switch Rating: | 230V AC, 2(1)Amp (per channel) |
| Contact Type: | 1B , Micro-Disconnection |
| Battery Type: | Lithium Cell CR2032 |
| Enclosure Protection: | IP30 |
| Plastics: | Thermoplastic, flame retardant |
| Insulation Class: | Double |
| Wiring: | For fixed wiring only |
| Backplate: | Industry standard |
| Dimensions: | 140mm x 87mm x 37mm |
| BST/GMT time change: | Automatic |
| Program Cycle | 24hr, 5/2day or 7day selectable. |
| Program On/offs per day: | 2on/off, 3on/off selectable |
| Program resolution: | 10mins Program Selection: Auto, On all day, On constant, off |
| Program Override: | 1, 2 or 3 hour, Advance |
| Heating System: | Pumped |
| Complies with: |
EN60730-1, EN60730-2.7, EMC Directive2004/108/EC, LVD Directive 2006/95/EC |
Sangamo Choice PR1n - Product Overview
Product overview of the Sangamo Choice PR1n. For further assistance in using Sangamo products you can call us on 01475 747 511.
