Takex 100m External / 200m Internal Twin Beam PB-100TK
The Takex 100m External / 200m Internal Twin photoelectric beams are designed to meet the highest standards of quality and reliability for photoelectric beam intrusion detection. These unique twin beams are synchronised to work together to reinforce range and stability in severe weather conditions.
For distances up to 100m (330ft) outdoor / 200m (660ft) indoor, the PB-100TK provides the ideal solution when cost is a major concern.
Features
- Synchronised Twin Beams for reliable detection
- Double Modulated Beam type ensures unsurpassed immunity to direct and reflected sunlight and vehicle headlights
- Multi-Meter Test Points to accurately monitor alignment voltage
- Frost Resistant Cover minimises nuisance alarms in harsh weather
- Automatic Gain Control for maximum stability
Specification
Product type Photoelectric Beam Sensor Detection system Simultaneous breaking of 2 beams Infrared beam LED pulsed beam, Double modulation Protection distance Outdoor 100m (330ft) or less
Indoor 120m (660ft) or lessBeam arrival distance (max.) Outdoor 1000m (3300ft) or less
Indoor 1000m (3300ft) or lessResponse time 50msec. to 700msec. (Variable at pot) Supply voltage 10V to 30VDC (Non-polarity) Current consumption 80mA or less Alarm output Dry contact relay output form C
Contact action : Interruption time + delay time
Contact capacity : 30V AC/DC, 0.5A or lessTamper output Dry contact relay N/C (Receiver only)
Action : Activated when cover is detached
Contact capacity : 30V AC/DC, 0.5A or lessAlarm LED Red LED (Receiver)
ON : when an alarm is initiated.Attenuation LED Red LED (Receiver)
ON : when beam is attenuated.Functions Multi-Meter Test Points
AGC circuit
Frost proof coverAmbient temperature range -25°C to +60°C (-13°F to +140°F) Mounting positions Indoor / Outdoor Wiring Terminals Weight Transmitter : 380g (13.3oz)
Receiver : 400g (14oz)Appearance PC resin (wine red)
