Wiska 20mm Cable Glands IP68 Red

Wiska 20mm Cable Glands IP68 Red 10100614

Wiska 20mm Cable Glands IP68 Red

SKU: GCG22R

20mm Cable Glands IP68, choose White, Black, Red or Light Grey. One Gland, One Solution. from Wiska. Price per gland.

Protection class	IP 69K / IP 68, 5 bar 30 min
Glow wire test	750 °C
Temperature range	-40 °C - 100 °C
Material	Screw: Polyamide, Gasket: EPDM

Specifications

Material cable gland	Polyamide
Material sealing gasket	EPDM
Temp. range min	-40 °C
Temp. range max	100 °C
Intermittent temp. range	120 °C
Protection class	IP 68, 5 bar 30 min, IP 69K
Thread type	M
Connection thread size D	20
Lead	1,5
Length screw-in thread L	9 mm
Cable diameter min	7,5 mm
Cable diameter max	14 mm
Key width SW	24 mm
Collar diameter (E)	27 mm
Total length TL	36 mm - 45 mm
Glow wire test	750 °C
Type of cable anchorage	A
Install. torques fitting	4 N/m
Install. torques cap nut	3 N/m

View more View less

Availability: 1,634

Qty:

Excl. Tax: £0.46 Incl. Tax: £0.55

We Accept:

Or Instant Pay with:

Description

20mm Cable Glands IP68, choose White, Black, Red or Light Grey. One Gland, One Solution. from Wiska. Price per gland.

Protection class	IP 69K / IP 68, 5 bar 30 min
Glow wire test	750 °C
Temperature range	-40 °C - 100 °C
Material	Screw: Polyamide, Gasket: EPDM

Specifications

Material cable gland	Polyamide
Material sealing gasket	EPDM
Temp. range min	-40 °C
Temp. range max	100 °C
Intermittent temp. range	120 °C
Protection class	IP 68, 5 bar 30 min, IP 69K
Thread type	M
Connection thread size D	20
Lead	1,5
Length screw-in thread L	9 mm
Cable diameter min	7,5 mm
Cable diameter max	14 mm
Key width SW	24 mm
Collar diameter (E)	27 mm
Total length TL	36 mm - 45 mm
Glow wire test	750 °C
Type of cable anchorage	A
Install. torques fitting	4 N/m
Install. torques cap nut	3 N/m
