ESP HDVIEW IP 16 Channel 16TB 5MP 1920p Resolution IP CCTV NVR | HDVIP16R16TB
The ESP HDVIEW IP 16 Channel 5MP 1920p Resolution IP CCTV NVR with 16TB hard drive provides straight forward installation for the growing demand for reliable domestic IP POE CCTV solutions.
The System features POE (Power-Over-Ethernet) which enables the camera and power feed to be wired in Cat5e cable up to 100 meters and making installations more convenient. The 5 Megapixel HDview IP range focuses on larger applications & all NVRs are packed with features such as remote monitoring via the ESP IPView APP, H265 compression, motion record activation and are supplied with quality surveillance Hard Drives for peace of mind.
- HD 5MP Resolution Viewing and Recording
- 16CH POE NVR- Power Over Ethernet
- H.265 Video Compression for Efficient Storage
- ONVIF Compliant
- Premium Surveillance Hard Drive (1TB, 2TB, 4TB, 8TB Options)
- Remote Monitoring via APP (Android / IOS) or PC
- Playback / Record / Remote View Simultaneously
- Continuous / Scheduled / Motion Record Modes
- HDMI Output (4K)
- USB Backup for Evidence Transfer
- Mouse Driven User Menu
- Contents: NVR, Power Supply, Manual, Software CD, HDMI Lead, Mouse Control, Remote Control (Battery Inc.)
System Operating System LINUX Recording Bandwidth 320Mbps POE 16CH (<100 Meters per Channel, Requires 4-Twisted Pair Cable) Video & Audio Video Input 16CH Audio Output 1CH Line In 1CH Display Output 1 x HDMI, 1 x VGA Display Split 1/4/6/8/9/10/13/14/16 Resolution 1024*768, 1280*720, 1280*1024, 1440*900, 1920*1080, 2560*1440, 3840*2160 Recording Compression H.265/H.264 Resolution 5 Megapixel Record Rate (Main Stream) 5 Megapixel Recording Mode Manual/Motion Detection/Schedule Playback & Backup Sync Playback 5 Megapixel Backup Mode Network / 2 x USB2.0 / 1 x USB3.0 / e-SATA Network Ethernet RJ-45 port (1000M? Network Functions HTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP Network Monitoring Web browser, Client Software, Android & IOS Storage Internal HDD 16TB HDD External HDD e-SATA < 4x6TB Interface Alarm In 16CH Alarm Out 1CH Data RS485 General NVR Power Consumption <12W (without hard disk) NVR Power Source IEEE802.3af Operation Condition 0ºC – +55ºC / 10% – 90% Dimensions 380X340X50mm Internal Power Supply Dimensions 380X340X50mm Power Output DC12V/8A, 53V DC/4.2A -280W
